How to Install Rightline Gear Side Storage Bag - Black (07-18 Wrangler JK 2 Door) on your Jeep Wrangler

1. Carefully open the package using a box cutter or knife (Figure A) and ensure the bag, insert and strap are included and undamaged.

2. Slide the hard-plastic insert (included) into the top sleeve (Figure B).

3. Place the bag above the wheel well behind the driver's seat (Figure C).

4. Run the rear-facing, bottom strap around the base of the rear vertical roll bar (Figure D) and buckle it back to the bag (Figure E).

5. Run the rear-facing, top strap around the rear vertical roll bar, above the seat belt holder, and buckle it back to the bag (Figure F).

6. Run the front-facing, top strap around the front vertical roll bar, above the seat belt (Figure G) and buckle it back to the bag (Figure H).

7. Tighten all the straps in place (Figure I).

8. Optional: Attach the included carry strap by pulling down on the clasp and placing it over the top D-ring (Figure J) on both top-facing D-rings.

Installation Instructions Written by ExtremeTerrain Customer J. Sandlin 11/15/2017.
