How to Install Factor 55 ProLink XXL - Black on your Jeep Wrangler

1. Carefully open the package using a box cutter or knife (Figure A) and ensure the ProLink XXL is included and undamaged.

2. Remove the lynch pin holding the current winch hook to the rope (Figure B).

3. With the lynch pin removed, pull out the bolt holding the hook to the winch rope (Figure C).

4. Remove the winch hook completely (Figure D).

5. Remove the snap ring from the ProLink XXL (Figure E).

6. Remove the placeholder bolt and place the winch rope inside the ProLink XXL (Figure F).

7. Reinsert the placeholder bolt (Figure G).

8. Place the snap ring back, ensuring it's seated completely in the snap ring groove (Figure H).

Installation Instructions Written by ExtremeTerrain Customer J. Sandlin 10/29/2017.
