Differential Torque Values
Differential Torque Values
| AXLE TYPE | COVER BOLTS FT. LBS. |
PIN. BEAR PRELOAD IN. LBS. |
PINION NUT FT. LBS. |
RING GEAR BACKLASH | RING GEAR BOLTS TO CAST FT. LBS. |
SIE BEAR CAPS FT. LBS |
|---|---|---|---|---|---|---|
| AMC 20 | 15 | 15-25 in.lbs | Pin. Preload Specs. | .005-.009 | 105 | 87 |
| Chrysler 8.25" | 15-25 | New 10-29 in.lbs Used 10-15 in.lbs |
Pin. Preload Specs. | .005-.008 | 75 | 100 |
| Chrysler 8.75" | 15-25 | New 20-35 in.lbs Used 10-15 in.lbs |
Pin. Preload Specs. | .006-.008 | 70 | 100 |
| Chrysler 9.25" | 15.25 | New 10-20 in.lbs Used 10-15 in.lbs |
Pin. Preload Specs. | .005-.008 | 115 | 100 |
| Dana 30 | 30-40 | 20-40 in.lbs | 200-220 | .005-.009 | 45-60 | 35-50 |
| Dana 35 | 30-40 | New 15-35 in.lbs Used 8-14 in.lbs |
Pin. Preload Specs. | .005-.008 | 70-89 | 47-67 |
| Dana 44 | 30-40 | 20-40 in.lbs | 200-220 | .005-.008 | 45-60 | 70-90 |
| Dana 60 | 30-40 | 20-40 in.lbs | 240-300 | .004-.009 | 100-120 | 80-90 |
| Dana 70 | 30-40 | New 20-40 in.lbs Used 10-20 in.lbs |
220-280 | .005-.008 | 100-120 | 80-108 |
| Dana 80 | 35 | New 20-40 in.lbs Used 10-20 in.lbs |
470 | .005-.008 | 220 | 80 |
| Ford 7.5" | 28-38 | New 16-28 in.lbs Used 8-14 in.lbs |
Pin. Preload Specs. | .008-.015 | 70-85 | 70-85 |
| Ford 8.8" | 28-38 | New 16-29 in.lbs Used 8-14 in.lbs |
Pin. Preload Specs. | .008-.015 | 70-85 | 70-85 |
| Ford 9" | 30-45 | New 22-23 in.lbs Used 10-14 in.lbs |
Pin. Preload Specs. | .008-.012 | 60-80 | 75-85 |
| Ford 9.75" | 28-38 | New 16-29 in.lbs Used 8-14 in.lbs |
Pin. Preload Specs. | .008-.015 | 100-120 | 70-85 |
| Ford 10.25" | 28-28 | New 16-29 in.lbs Used 8-14 in.lbs |
Pin. Preload Specs | .008-.015 | 100-120 | 70-85 |
| Ford 10.5" | 28-38 | New 16-20 in.lbs Used 8-14 in.lbs |
Pin. Preload Specs. | .008-.015 | 100-120 | 75-85 |
| GM 7.5" | 20 | New 24-32 in.lbs Used 8-12 in.lbs |
Pin. Preload Specs. | .005-.009 | 90 | 60 |
| GM 8.5" | 20 | New 20-25 in.lbs Used 10-15 in.lbs |
Pin. Preload Specs. | .005-.009 | 90 | 60 |
| GM 8.87" | 20 | New 20-25 in.lbs Used 10-15 in.lbs |
Pin. Preload Specs. | .005-.09 | 90 | 60 |
| GM 9.5" | 20 | New 20-25 in.lbs Used 10-15 in.lbs |
Pin. Preload Specs. | .005-.009 | 105 | 60 |
| GM 10.5" | 20 | New 20-25 in.lbs Used 10-15 in.lbs |
Pin. Preload Specs. | .005-.009 | 105 | 100 |
| Toyota 7.5" | 40-45 | New 12-19 in.lbs Used 8-12 in.lbs |
Pin. Preload Specs. | .005-.007 | 72 | 63 |
| Toyota 8" | 54 | New 12-19 in.lbs Used 8-12 in.lbs |
Pin. Preload Specs. | .005-.007 | 72 | 63 |
| Toyota L.C. | 35 | New 14-19 in.lbs 8-12 in.lbs |
Pin. Preload Specs. | .005-.007 | 101 | 63-83 |
