How to Install a RedRock 4x4 Light Bar on your 2007-2017 Jeep Wrangler JK

Installation Time

2 hours

Tools Required
  • T40 Torx
  • 1/2” socket
  • 5mm allen
Extreme Terrain
Shop Parts in this Guide

Contents:

(1) - Light Bar
(2) - Bolts
(2) - Lock Nuts
(4) - Washers

It is recommended that you have an additional person available to help during this installation, parts can be awkward to hold and support by yourself.


The light bar sections are large and can be awkward to handle. It is recommended that you cover the area surrounding the windshield mount with painters tape to help protect from any scratches during installation.


Remove the (4) outer torx head bolts shown above.


Start by mounting the vertical windshield mount first on one side, by installing the stock torx head bolts through the vertical support plate. Then install the horizontal bar. Keep all hardware loose at this point.

Be sure to check the clearance between the mounting stud on any lights installed on the horizontal bar and the top of the windshield, some lights may require you to trim the bottom of the stud. It may also help to wedge a rag between the windshield and bar to prevent any scratches.


First slide the top of the bar into the horizontal section and loosely install the provided nut, bolt, and washers. Next, install the horizontal windshield bar. Double check that everything is aligned properly before tightening the rest of the hardware in place.
