How to Install Raxiom LED Fog Lights on your Mustang
Installation Time
1 hours
Tools Required
- Flat Screw Driver
- Phillips Screw Driver
- Wire Stippers
**NOTE: Removal of bumper is not necessary but can make the job easier.
Step 1:
Remove the 6 pins holding the splash guard onto the vehicle
Step 2:
Next, unplug the factory fog lights and loosen the (8) 19mm nuts holding the front bumper to the support
beam of the vehicle.
Step 3:
To remove the fog lights, loosen the 4 phillips screws on each light.
Step 4:
Wire LED Pigtail. Blue wire to factory black wire. Brown Wire to the factory White or white and red wire.
Step 5:
Follow steps 1-3 in reverse.
