(approx) 2 Hours
Simple installation for anyone.
Open Box from $89.20
Hey, guys. Today, I'm here with the Barricade tubular fender flares fitting all '07 to '18 two-door and four-door JKs. This is going to be for the guys out there looking for a tough off-road look, some better protection for the side body of your JK, as well as a flat fender to allow more up travel for larger wheels and tires. This is going to be your most affordable option at the moment at roughly $350 for either the front or the rear and at roughly $700 for a set of all four. Compared to other options on the page for only the front, those are going to cost roughly the same amount as all four of these so, I think you're getting a great deal out of these. Install will be a strong one out of three wrenches and there's not going to be any drilling required, however, you might have to wrestle the fender on there to get all of the bolt holes to line up. So, so speaking of the install, let's jump into that now. So, our first step to remove our stock fender is to remove the six bolts holding it on. So, we're going to be removing these six 10-millimeter bolts holding on our fender flare up around the liner. So, after we remove those six bolts, we need to unplug our side marker light harness. You can just pull the inner fender liner back, and there should be a tab and you can pull that out. So, this part's not going to sound great, but all you have to do is pull off your fender and pull the pop clips out of the body. So after that, you can rest your fender on the wheel and disconnect your side marker light harness. So, we're not going to be reusing this harness, so we can fully unclip it.With our harness removed, we can fully remove our fender assembly. So, in order to remove our rear fender, we have four pop clips inside of our inner fender liner that we're going to pull out so we can remove the full fender. I'm using a trim removal tool. So now, we can remove our rear fender just like we did our front and just pull it out. So after pulling the fenders off, just make sure if you do have any remaining clips, that you remove those so we can install our new ones. You can just take a trim removal tool and they should pop out pretty easy. Just be careful because these ones are crazy. So, there are two ways that you can go with a fender flare. You can choose a plastic option like the stock one. However, when you're off-road, if you do hit something, they can bend or break. But the good thing about that is that they will just pop right off and not transfer any of that energy into your body, causing any extra damage that you might not want. Or you could go with a tubular fender like this one from Barricade. This is going to be a lot more durable than the stock fender flare being made of carbon plated steel. However, if you do take a hard enough hit, you will transfer some of that energy into your body and essentially causing a little bit more damage than you might want. Nonetheless, if you are in favor of this tubular option, then it will be a more durable setup overall, and will also come with a black powder coat finish to resist any of that rusting or corrosion. This will also be a flat flare. So when you're off-road, you're going to get a lot more articulation and up travel out of this flare than you would the stock. Not to mention, you are going to get a very aggressive and off-road look with these new fender flares. So enough about the stock fender flare, let's put on our Barricades. So now, we can bolt up our Barricade to the fender. They provided us with a notch here, so we can rest the fender on this bracket and bolt up our hardware. So after it's resting on this bracket, we can loosely attach our hardware. And the reason why we loosely attach it is so we can shimmy the fender around to get in all of the other bolts. So now that all of our hardware is in and everything's lined up, we can tighten everything down with an extended Allen key, it's going to be a 5-millimeter, and a 13-millimeter wrench.So once our hardware is loosely installed, we can take our rubber gasket with the flat side facing the inside of the Jeep and insert it in between the body and the fender. So once we have it where we want it, we can cut our excess off so we can use it on the other side. And this is going to give the fenders a more finished look and protect the paint on your body. So with our gasket installed, we can tighten all of our hardware using a 5-millimeter Allen key and a 13-millimeter wrench. So after we have our fender all buttoned up, we can do the same thing on the other side and then move to the rear.So unlike the front, we can only access two of the bolt holes, so Barricade provided us with rivnuts to be inserted in the rest of the holes. So, with the help of a friend holding the flare, we're going to loosely install our hardware. So, with all of our hardware loosely installed, just like the front, we're going to install our gasket and then tighten everything down. For the bolts with the rivnuts, you're going to be using a 4-millimeter Allen key. And for the bolts with the nuts on the back, you can use a 5-millimeter Allen key and a 13-millimeter wrench.So, after everything's tightened down, then you're all set to go. That's it for my review and install on the Barricade tubular fender flares fitting all '07 to '18 two-door and four-door JKs. For more videos like this, keep it right here at extremeterrain.com.
Subscribe to our YouTube Channel
Features, Description, Reviews, Q&A, Specs & Installation
Fitment: 2007 2008 2009 2010 2011 2012 2013 2014 2015 2016 2017 2018 Details
CA Residents: WARNING: Cancer and Reproductive Harm - www.P65Warnings.ca.gov
January 15, 2020
I bought these, had trouble installing them, so I went to my local Jeep Shop. The fenders don't line up! they were made wrong and now I have to send them back. Get another kind of fender! These are a waste of time and money!Helpful (2)
January 05, 2020
Great product (Back fenders)
Loved the back fenders have a great look to them and fit nicely only complaint is the need for a rib nut tool, its a tool that you wont normally have lying around the garage and you will either have to rent it or buy one (most likely a one time use tool you wont need again I would recommend renting). Otherwise great product!Helpful (2)
November 14, 2018
Look awesome!!!! Very sturdy. The installation was tough, had to drill new holes because they didn’t line up.Helpful (13)
May 05, 2018
Good quality product, tough installation
Taken alone, the fenders are solidly built and definitely add protection and a good rugged appearance compared to the stock fenders. They give the jeep the appearance of a lift without doing a lift since they’re flat vs. the stock fenders that have a downward angle. Now for the not so great aspects, the installation of the rear fenders wasn’t easy. The installation hardware includes rivnuts but no instructions on how to install them. By the book rivnuts requie a special tool but I found instructions on YouTube to do the installation with no special tools needed. Once I figured out the proper technique it was easy and the installation probably took me 5-6 hours for the front and rear.Helpful (14)
April 08, 2018
Wanted the Look, Not the Pain
I loved the way these looked in pictures. I LOVE the way they now look on my JKU. Buy these if you love them as well, I recommend. Now for the but. The front fenders went on pretty easily. Although one hole on each was not lined up. It took some grinding with a dremel tool to make it fit. The rear on the other-hand was a bear. There are pins to insert to hold some screws, they just pull out, you will need to epoxy them in. The holes just barely line up, i had to use a jack to make one align. The rubber gasket is near impossible to install, but with some time and patience it fits. Overall they look fabulous. If you are not mechanically inclined or have extreme patience, do not buy these.Helpful (17)
February 26, 2018
Barricade Tubular Fender Flares
I really like the style of the fenders and the way they look overall. The reason for the 2 star rating is, when i first ordered them, the front fenders both fit fine, but the back did not at all. So I had to send them back and it was a a huge hassle. Also some of the fenders had rust on them in small areas.Helpful (12)
December 08, 2017
Front fenders went on well. Rear fenders were trouble. The fenders weren't bent right. Needed more curve to them. Also, the plugs they give you to go into existing holes popped right out when you tighten the screws. I had to use apoxy to hold them in. One still pops out. I love the look. Just could have been better.Helpful (18)
December 02, 2017
Not so good so far
First set of bumpers all came marred with scratches, chunks of metal cut out, and poor powdercoating. The packaging was fine so this was not caused by shipping. Extreme terrain was very courteous and immediately issued a pre paid label for return... ufortunately I had to remove my fender flares to put on larger tires...now I have none!Helpful (16)
November 23, 2017
Good deal for the price.
The holes didn't all line up like they were suppose to and there were some scuffs from the shipping. A little paint and it was fixed though.Helpful (13)
November 15, 2017
Barricade Tubular Fender Flares
Good Fit, Easy to Install, Gives the Wrangler nice clean lines.Helpful (15)
Do the rear fenders conform to the factory contour sweep or do they fit outside the contours.
The Barricade Rear Tubular Fender Flares will line up with the factory rear contour.
is it front and rear or just rear. shows picture of both but when you check out it says only rear in fine print
These would just be the rear flares.
Will these fenders work with the Poison Spyder inner fender kits, front back? Thank you.
These fenders should work with the Poison Spyder Fender Liners, but they may require a little modification.
What size are the rivets? I bought some rear fenders that required M8 and I want to replace them.
Is this for the front and the rear?
This is for the rear flares only.
We do not rate these to be stood on and would not suggest it.
(approx) 2 Hours
Simple installation for anyone.
What's in the Box
