Barricade 12,000 lb. Winch with Synthetic Rope (Universal; Some Adaptation May Be Required)

Item FB6789
On Sale

-10% $408.99 each Was $454.99

Coupon
Apply 10% Discount
One coupon per order | Details
Military, Medical & First Responders $40.90 Available in XT Cash Rewards.
Confirm Eligibility

Choose options to add to cart.
    Create a list
    Add to New List

    Saved - View your saved items

    We're sorry. We couldn't save this product at this time.

    or use

    Shop Owners Save More! Sign up for our dealer program

      Product Information

      Features, Description, Reviews, Q&A, Specs & Installation

      Features & Specs

      • 12000lb Line Pull Rating
      • Weight: 44 lbs
      • 6.6 HP 12-Volt Series Wound Electric Motor
      • Three Stage Planetary Gear with 187.2:1 Gear Ratio
      • Bright Orange Synthetic Rope Included
      • Remote Switch with 12 Foot Lead
      • Durable Black Powder Coat Finish
      • Overall Dimensions 21.1 × 6.3 × 8.6 Inches
      • Mounting Bolt Pattern 254mm X 114.3mm
      • Fits All 2021-2026 Bronco Models

      Description

      Be Prepared. Whether you are a novice or serious off-roader you should take a page out of the Scouts hand book and "be prepared" for what the trail might throw at you, that's why your Bronco should be outfitted with a reliable recovery system like Barricade Off-Roads 12000lb heavy duty winch.

      Heavy Duty Winch. The Barricade Off-Road 12000lb Winch is driven by a powerful 6.6 HP series-wound 12-volt electric motor and features a rugged 3-stage planetary gear box with a 187.2:1 gear ratio to provide 12000lbs of pulling power to get you out of the messiest situations.

      Additional Features. Barricade Off-Roads 12000lb Winch features a sliding ring gear clutch, a two-way automatic in-the-drum braking action, a 2.5 x 8.8 inch drum, a hawse fairlead, and includes a 94-foot bright orange synthetic rope.

      Application. This Barricade Off-Road 12000lb Winch is designed for use on all 2021-2026 Bronco.

      Technical Note. A battery with a minimum of 650cca (cold cranking amps) is required for operation.

      Please Note. To prevent damages to the synthetic rope from sun and weather this winch requires a cover when not in use. Winch cover not included - sold separately.

      Line Pull Speeds

      • 0 lbs. - 33.3 ft./min
      • 4000 lbs. - 16.8 ft./min
      • 6000 lbs. - 12.8 ft./min
      • 8000 lbs. - 10.1 ft./min
      • 10000 lbs. - 8.8 ft./min
      • 12000 lbs. - 7.6 ft./min

      • Replacement Hardware – SKU U2405H

      Barricade Off-Road

      Barricade J103901

      CA Residents: WARNING: Cancer and Reproductive Harm - www.P65Warnings.ca.gov

      Installation & What's in the Box

      Installation Info

      What's in the Box

      • (1) Hexagon screw
      • (1) Spring washer M5
      • (1) Clutch handle
      • (1) Nut cap
      • (1) Cup gasket
      • (1) Spring washer Φ20
      • (2) O-ring
      • (1) Gear box housing
      • (1) shaft sleeve
      • (1) sun gear
      • (1) 3rd Planetary gear assy
      • (1) Dual inner gear
      • (1) 2nd Planetary gear assy
      • (1) 1st Planetary gear assy
      • (1) Sealing washer
      • (4) Hexagon screw M8x25
      • (4) Spring washer Φ8
      • (1) Gear box bracket
      • (10) Spring washer Φ4
      • (10) Hexagon screw M4x20
      • (2) Bearing bush
      • (2) Sealing washer
      • (1) Transmission shaft
      • (1) Drum assembly
      • (1) Brake assembly
      • (2) Tie bar
      • (1) Motor assembly
      • (4) Cross Recess Head Screw M4.2X12
      • (2) Mounting bracket assembly for control box
      • (1) Control box assembly
      • (1) Fairlead
      • (1) 3/8" Hook
      • (1) Wired remote control
      • (1) Battery negative (-) cord 1.8M
      • (1) Wireless remote control (Optional)
