Jeep Wrangler JK Engine Torque Specs

Written By:

Contents
  1. A/C System Torque Specs
  2. 3.8L Engine Torque Specs
  3. 2.8L Engine Torque Specs
Shop Wrangler JK Engine Parts



Shop Engine Parts

A/C System Torque Specs

These torque specs cover all of the important components of your Wrangler’s A/C System. For most of the screws they can simply be snugged up with your screwdriver.

Description

Specification



A/C Expansion Valve Nut

17 ft-lbs



A/C Compressor Bolts

21 ft-lbs



A/C Compressor Clutch Field Coil Screws

44 in-lbs



A/C Compressor Shaft Bolt

177 in-lbs



A/C Compressor Field Coil Connector Bracket Screw

38 in-lbs



A/C Condenser To Radiator Bolts

45 in-lbs



A/C Heater Control Screws

17 in-lbs



Air Inlet Housing To Instrument Panel Support Bolts

35 in-lbs



Blend Door Lever Screw

5 in-lbs



Discharge Line To Condenser Nut

17 ft-lbs



Discharge Line To Compressor Nut

17 ft-lbs



Expansion Valve Bolts

97 in-lbs



HVAC Housing To Instrument Panel Support Bolts

35 in-lbs



Liquid Line To Condenser Nut

17 ft-lbs



Mode Door Cam Screw

5 in-lbs



Receiver/Drier To Condenser Bolt

16 ft-lbs



Suction Line To Compressor Nut

17 ft-lbs



Suction and Liquid Lines To Expansion Valve Nut

70 in-lbs



3.8L Engine Torque Specs

If you are rebuilding your engine or simply changing your oil, the torque specs for your 3.8L engine are all in this table.For quick reference the oil pan drain plug should be tightened to 20 ft-lbs.

Description

Specification



Camshaft Sprocket Bolt

40 ft-lbs



Camshaft Thrust Plate Bolts

105 in-lbs



Forged Connecting Rod Cap Nuts

40 ft-lbs 90 Degrees



Crankshaft Main Bearing Cap Bolts

30 ft-lbs 90 Degrees



Crankshaft Main Bearing Cap Cross Bolts

45 ft-lbs



Crankshaft Oil Seal Retainer Rear Bolts

105 in-lbs



Crankshaft Damper Bolt

40 ft-lbs



Cylinder Block Drain Plugs

15 ft-lbs



Cylinder Head Cover Bolts

105 in-lbs



Flex Plate To Crankshaft

65 ft-lbs



Exhaust Manifold Bolts

200 in-lbs



Intake Manifold Lower Bolts

200 in-lbs



Intake Manifold Lower Gasket Retainer Bolts

105 in-lbs



Intake Manifold Upper Bolts

105 in-lbs



Lifter Yoke Retainer Bolts

105 in-lbs



Oil Filter Attaching Fitting

40 ft-lbs



Oil Cooler Attaching Fitting

20 ft-lbs



Oil Filter

15 ft-lbs



Oil Filter Adapter Bolts

250 in-lbs



Oil Gallery Plug

20 ft-lbs



Oil Pan Bolts

105 in-lbs



Oil Pan Drain Plug

20 ft-lbs



Oil Pressure Switch

200 in-lbs



Oil Pump Cover Plate Screws

105 in-lbs



Oil Pump Pick-Up Tube Bolt

250 in-lbs



Oil Dipstick Housing Bolts

35 ft-lbs



Rocker Arm Shaft Bolts

200 in-lbs



Spark Plug

12 ft-lbs



Thermostat Housing

105 in-lbs



Timing Chain M8 Bolt

20 ft-lbs



Timing Chain M10 Bolt

40 ft-lbs



Water Pump Bolts

105 in-lbs



Water Pump Pulley Bolts

250 in-lbs



Accelerator Pedal Bracket Mounting

105 in-lbs



Crankshaft Position Sensor - 3.8L

21 ft-lbs



Camshaft Position Sensor - 3.8L

106 in-lbs



Fuel Filler Hose Clamp at Tank

30 in-lbs



Fuel Filler Housing To Body Screws

17 in-lbs



Fuel Rail Mounting Bolts - 3.8L

17 ft-lbs



Fuel Tank Mounting Straps

30 ft-lbs



Throttle Body Mounting Bolts - 3.8L

5.5 ft-lbs

Oxygen Sensors

30 ft-lbs

2.8L Engine Torque Specs

If you are rebuilding your engine or simply changing your oil, the torque specs for your 2.8L engine are all in this table. For quick reference: The oil drain plug should be tightened to 40 ft-lbs.

Description

Specification



Lower Oil Pan

12 ft-lbs



Upper Oil Pan M6 Bolt

12 ft-lbs



Upper Oil Pan M8 Bolt

23 ft-lbs



Oil Pickup Tube

12 ft-lbs



Oil Drain Plug

40 ft-lbs



Balance Shaft

23 ft-lbs



Dipstick Tube (Sump)

8 ft-lbs



Dipstick Tube (Block)

24 ft-lbs



Oil Cooler Coolant Line

12 ft-lbs



Transmission Adapter Bolts (Hex Head)

12 ft-lbs



Transmission Adapter Bolts (Allen Head)

57 ft-lbs



Oil Jet

8 ft-lbs



Engine Mount Bolts

9 ft-lbs



Oil Filter Cap

221 in-lbs



Oil Pressure Sensor

10 ft-lbs



Air Temp/Pressure Sensor

9 ft-lbs



Cylinder Head Cover

8 ft-lbs



Vacuum Tube

8 ft-lbs



Fuel Rail

18 ft-lbs



Fuel Injector Lines At The Injector

20 ft-lbs



Fuel Injector Lines At The Fuel Rail

15 ft-lbs



High Pressure Fuel Feed Line at the Fuel Rail

15 ft-lbs



High Pressure Fuel Feed Line at the High Pressure Pump

20 ft-lbs



High Pressure Fuel Line Bracket Bolt

11 ft-lbs



Fuel Injector

24 ft-lbs



Glow Plugs

10 ft-lbs



EGR Throttle Assembly

8 ft-lbs



Exhaust Manifold

29 ft-lbs



Camshaft Sprocket

47 ft-lbs



Camshaft Cap

8 ft-lbs



Front Camshaft Journal

8 ft-lbs



Intake Manifold

19 ft-lbs



Outer Front Cover (Upper)

8 ft-lbs



Outer Front Cover (Lower)

8 ft-lbs



Inner Front Cover

8 ft-lbs



Front Cover

12 ft-lbs



Crankshaft Sprocket

74 ft-lbs 75 Degrees



Crankshaft Pulley

23 ft-lbs



Front Engine Lifting Bracket

33 ft-lbs



Accessory Drive Idler Pulley

33 ft-lbs



CMP Sensor

8 ft-lbs



Water Pump

23 ft-lbs



Timing Belt Tensioner

15 ft-lbs



Rear Cover

10 ft-lbs



Rear Lifting Bracket

33 ft-lbs



Crankshaft Sensor

8 ft-lbs



CKP Cover Plate

11 ft-lbs



Trans Adapter Plate Allen Bolts

58 ft-lbs



Trans Adapter Plate Hex Bolts

33 ft-lbs



Power Steering Pump Pulley

24 ft-lbs



Power Steering Pump

24 ft-lbs



Generator

24 ft-lbs



Generator Bracket

33 ft-lbs



A/C Compressor

23 ft-lbs



A/C Compressor Bracket

33 ft-lbs



Turbocharger

23 ft-lbs



Turbocharger Oil Feed Line At The Turbocharger

18 ft-lbs



Turbocharger Oil Feed Line At The Engine Block

23 ft-lbs



Turbocharger Oil Return Line

11 ft-lbs



Turbocharger Brace

23 ft-lbs



Turbocharger Adapter (Oil Feed Line To Engine Block Connection)

40 ft-lbs



EGR Valve

11 ft-lbs



EGR Cooler

11 ft-lbs



High Pressure Fuel Pump

18 ft-lbs



High Pressure Fuel Pump Sprocket.

65 ft-lbs



Oil Cooler Housing

23 ft-lbs



Oil Cooler Feed Line

8 ft-lbs



Crossmember To Sill Bolts

31 ft-lbs



Crossmember To Transmission Mount Nuts

16 ft-lbs



Exhaust Manifold To Engine Bolts 6&7

23 ft-lbs



Exhaust Manifold To Engine Bolts 1,2,3,4,5,8,9,10,11

24 ft-lbs



Catalytic Converter To Turbocharger Nuts

19 ft-lbs



DPF To Catalytic Converter Bolt

24 ft-lbs



DPF To Muffler Bolts

24 ft-lbs



Clamp, Tailpipe To Rear Tailpipe Hanger

20 ft-lbs



Oxygen Sensors

20 ft-lbs



Heat Shields

33 ft-lbs



Front Bumper Support Bolts

66.5 ft-lbs



Fuel Tank Skid Plate To Crossmember Bolts

73 ft-lbs



Rear Bumper Support Bolts

18.5 ft-lbs



Rear Bumper Support Bracket To Frame Bolts

40.5 ft-lbs



Trailer Hitch/Rear Tow Hook Bolts

60 ft-lbs



Transfer Case Skid Plate Crossmember Bolts

48 ft-lbs



Transfer Case Skid Plate Support Bracket Bolts

48 ft-lbs



Transmission Crossmember Bolts

90 ft-lbs



Transmission Skid Plate Support Crossmember Bolts

48 ft-lbs



Transmission Skid Plate To Crossmember Bolt

48 ft-lbs
