How to Install GraBars Driver & Passager Side Utility Shelf w/ Quick Fist Clamp (07-18 Wrangler JK 4 Door) on your Jeep Wrangler
Shop Parts in this Guide
1. Remove the hard top from the vehicle (Figure A).
Figure A
2. Align the driver's side utility shelf with the hard top mounting holes with the shelf facing the front of the vehicle (Figure B).
Figure B
3. Insert one torx bolt into the driver's side utility shelf (Figure C).
Figure C
4. Insert the other torx bolt into the driver's side utility shelf (Figure D).
Figure D
5. Tighten both bolts onto the driver's side utility shelf using a torx 30 bit (Figure E).
Figure E
6. Align the passenger's side utility shelf with the hard top mounting holes (Figure F).
Figure F
7. Insert one torx bolt into the passenger's side utility shelf (Figure G).
Figure G
8. Insert the other torx bolt into the passenger's side utility shelf (Figure H).
Figure H
9. Tighten both bolts onto the passenger's side utility shelf using a torx 30 bit (Figure I).
Figure I
Before
After
Installation Instructions Written by ExtremeTerrain Customer J. Sandlin 07/17/2018
