BluePrint Engines Standard Edition Builder Series Small Block Chevy 454 C.I. 563 HP Fuel Injected Crate Engine and 700R4 Automatic Transmission with Polished Pulley Kit
Item U19362-XT
Our Price
$22,099.00
Military, Medical & First Responders
$1,104.95 Available in XT Cash Rewards.
Confirm Eligibility
Confirm Eligibility
Choose options to add to cart.
Saved - View your saved items
We're sorry. We couldn't save this product at this time.
or use
Shop Owners Save More!
Sign up for our dealer program
Product Information
Features, Description, Q&A, Specs & Installation
Features
- 563 Horsepower / 545 Ft. Lbs. Torque
- BluePrint Engines Aluminum Cylinder Heads
- Compression Ratio 10.5:1
- Hydraulic Roller Camshaft With .638 Intake / .622 Exhaust Lift And 251 Intake / 259 Exhaust Duration At .050 – 114 Lsa
- Forged Pistons
- Forged Steel Crankshaft With 4.000" Stroke And Forged 6.000" Rods
- Fuel Recommendation 91+ Octane
- BluePrint Engines High Strength Cast Iron Block Manufactured And Machined In The USA
- Drilled And Tapped For Clutch Linkage
- Mechanical Fuel Pump Provision
- Passenger Side Dipstick
- 1-Piece Rear Main Seal
- 4-Bolt Main
- 4.250" Bore
- BluePrint Forged Crankshaft, Internally Balanced Front And Rear
- BluePrint Aluminum Cylinder Heads With 64cc Chamber, 2.08" Intake / 1.60" Exhaust Valves, 220cc Intake / 67cc Exhaust Runners
- Initial Timing 10-16° And Total Timing 32-34°
- Pro Series Ready Run Distributor
- Single Plane Intake Manifold
- Holley Sniper 2 EFI System
- Thermostat And Thermostat Housing
- Valve Covers, Spark Plugs And Wires
- EFI Fuel Pump Kit
- Timing Cover And Oil Pan
- Polished Front Accessory Drive With Reverse Rotation Short Water Pump, Type II Power Steering Pump, Remote Power Steering Pump Reservoir, 140amp 1-Wire Alternator, 7B10 Peanut Style Air Conditioning Compressor
- Complete 700R4 Automatic Transmission Package Including 2200-2400 Stall Torque Converter, Flex Plate, Starter
- Not For Use In Pollution-Controlled Vehicles
- Performance Aluminum Cylinder Heads Feature A .500 Raised Port
- Fits: Small Block Chevy 454 Cubic Inch Configurations
Description
High-Performance Powertrain. The BluePrint Engines Standard Edition Builder Series Small Block Chevy 454 C.I. 563 HP Fuel Injected Crate Engine and 700R4 Automatic Transmission with Polished Pulley Kit provides a powerful and reliable package for enthusiasts seeking substantial horsepower and torque. This stroked small block engine is paired with a capable automatic transmission, designed for a variety of high-performance builds and restorations.
Construction and Appearance. Built with a high-strength cast iron engine block, forged steel crankshaft, and forged pistons, the engine emphasizes durability and strength. It incorporates aluminum cylinder heads and features a polished front accessory drive with a reverse rotation short water pump, a 140-amp 1-wire alternator, and 7B10 peanut style air conditioning compressor, delivering a clean, professional appearance ideal for engine bays.
Installation. The engine block is drilled and tapped for clutch linkage and includes provisions for mechanical fuel pumps. Installation requires careful fitment confirmation due to the compact, performance-oriented design. Customers should measure accessory clearance and plan hose and wiring routing accordingly. Additional fittings or modifications may be necessary depending on the vehicle application.
Warranty. This engine and transmission package includes a standard warranty of 30 months or 50,000 miles covering parts and labor, providing confidence in long-term performance and reliability, subject to warranty terms and eligibility.
Application. Specifically designed as a stroked small block Chevy 454 cubic inch compatible crate engine with a 700R4 automatic transmission, this package is not intended for use in emissions-controlled vehicles. Customers should verify accessory fitment and vehicle compatibility due to its performance-focused design.
BluePrint Engines B454FK700
