How to Install BedRug Front Floor Liners (97-06 Wrangler TJ) on your Jeep Wrangler
Shop Parts in this Guide
Congratulations on choosing the finest interior flooring kit available for your Jeep. The Bedrug/Bedtred material is mold and mildew resistant, easily cleaned with water & household cleaning chemicals and extremely resistant to most chemicals.
Kit Contents: Driver side front floor, passenger side front floor, rear passenger floor, heat shield material, hook fasteners, and instruction sheet.
WARNING: The use of front floor mats is not recommended with BedRug or BedTred floor kits. If floor mats are used, it is imperative to re-use the removable retention hooks from the factory carpet, installed to the manufacturers specifications.Do not use floor mats or liners with BedTred Kits, do not use floor mats or liners with BedRug Kits without retention hooks.**Please retain these instructions for future reference in your vehicles glove box**
PREPARATION
1. Read all instructions before beginning installation.
2. Remove old Jeep flooring material (if equipped).
3. Wash and dry the floor pan areas thoroughly.
4. Place the hook fasteners on each piece of loop sewn on the back side of the BedRug. For BedTred installation, place the hook fasteners to the loop surface on the underside of the BedTred. Use drawing on Page 4 for proper location.
5. Pre-install provided heat shields on underside of the two front pieces in areas (see Page 4), using the locator marks. (Fig. 1 & Fig. 2) Note: Passenger side heat shield is the larger of the two pieces.
IMPORTANT: Jeep floor should be at least 68°F (20°C) for maximum adhesion. Clean all areas with rubbing alcohol before applying tape. When removing backing, do not touch adhesive. If both front and rear kits were purchased be sure to install the rear cargo area first.
INSTALLING FRONT FLOOR PIECES
6. Adjust the front seats to the rear most position to allow maximum clearance for installation. Place front floor pieces into place. (Fig. 5) Tuck under console and around seat brackets as shown. (Fig. 6) (Tip: removing bolts from rear and/or front cup holders will allow console to lift up and position liner underneath easily - Reference picture 9)
7. Once properly aligned, pull back part to access the two pieces of hook fastener (Fig. 7). Clean surface with alcohol then remove the film backing and roll the part back into place. Firmly press the top surface to ensure adhesive attachment. (Fig. 8) Repeat for other front floor piece.
INSTALLING REAR FLOOR PIECE
8. Adjust the front seats to the fully forward and tilted up (passenger entry) position. Loosen the two screws located in the bottom of the cup holders on the rear of the console if equipped. (Fig. 9) Next place the rear floor piece into place. (Fig. 10)
9. Tuck the part under the console and around the front seat brackets as shown. (Fig. 11 and Fig.12)
10. Next lift the floor piece from the outside of the vehicle toward the center to access the hook fastener. (Fig. 13) Clean surface with alcohol then remove the film backing from both pieces and roll the floor back into place. Firmly press the top surface to ensure adhesive attachment.
11. Now fit and tuck part around seat brackets, roll bar, and seat belt mounts. (Fig. 14) Repeat for opposite side of vehicle.
12. Retighten the two console screws located in the bottom of the cup holder.
BEDTRED HOOK & LOOP PLACEMENT
