2024-2026
2016-2023
2005-2015
Installation Time
(approx) 1 Hour
Difficulty Level:
Simple installation for anyone.
Installation Guides
No guide available for this part yet.
FREE 1 to 3-Day Delivery on Orders $149+ Details
Find Light Bars & Off-Road Lighting for your Tacoma
Baja Designs LP6 Pro LED Auxiliary Light Pod with Red Backlight; Spot Beam; Clear (Universal; Some Adaptation May Be Required)
Item TT44336
Our Price
$524.95 each
Military, Medical & First Responders
$26.25 Available in XT Cash Rewards.
Confirm Eligibility
Confirm Eligibility
Choose options to add to cart.
Saved - View your saved items
We're sorry. We couldn't save this product at this time.
or use
Shop Owners Save More!
Sign up for our dealer program
Product Information
Features, Description, Reviews, Q&A, Specs & Installation
Features & Specs
- _x000D_
- Lens Color Clear _x000D_
- Lens Material Hardcoated Polycarbonate _x000D_
- Light Quantity 1 _x000D_
- Lighting Modes High Beam / Low Beam / Daytime Running Backlighting _x000D_
- Lighting Quantity 6 _x000D_
- Lighting Technology LED _x000D_
- Lighting Type Forward Projecting _x000D_
- Mounting Hardware Included Yes _x000D_
- Mounting Hardware Material Stainless Steel _x000D_
- Overvoltage Protection Built-In _x000D_
- Product Type LP6 Pro LED Light Pod _x000D_
- Secondary Amperage Rating A 1.000 _x000D_
- Secondary Brightness Lumens 1972 _x000D_
- Secondary Light Quantity 4 LEDs _x000D_
- Secondary Lighting Technology LED _x000D_
- Secondary Lighting Type Integrated Peripheral Technology (IPT) _x000D_
- Secondary Wattage W 15 _x000D_
- Terminal Connector DT06-4S Deutsch _x000D_
- Terminal Type Mating Connector _x000D_
- Universal Or Specific Universal _x000D_
- Wattage W 103.5 _x000D_
- Wiring Harness Included No _x000D_
- Amperage Rating A 7.5 _x000D_
- Average Rated Life Hr 49930 _x000D_
- Backlight Amperage Rating A 0.3 _x000D_
- Backlight Wattage W 4.14 _x000D_
- Beam Pattern Spot _x000D_
- Bezel Material Powder Coat Cast Aluminum _x000D_
- Brightness Lumens 11225 _x000D_
- Description Spot Clear _x000D_
- Housing Color Black _x000D_
- Housing Material Powder Coat Cast Aluminum _x000D_
- Standards Compliance Durability Exceeds MIL-STD-810G Mil-Spec Testing _x000D_
- Standards Compliance Impact Resistance IK10 Compliant Mechanical Impact Testing _x000D_
- Standards Compliance Water Resistance IP69K Waterproof Up To 9 ft and Pressure Washable _x000D_
- Depth Inches 3.2 _x000D_
- Height Inches 6.5 _x000D_
- Length Inches 6.5 _x000D_
- Weight Lbs 4.2 _x000D_
- Fits Universal; Some Adaptation May Be Required _x000D_
| Brand | Baja Designs |
| Bulb Type | LED |
| Light Shape | Round |
| Light Size | 6 to 7.75 Inch |
Description
Powerful Auxiliary Lighting. The Baja Designs LP6 Pro LED Auxiliary Light Pod with Red Backlight and Spot Beam in Clear lens is engineered to deliver exceptional illumination for off-road and auxiliary applications. It provides broad and intense light coverage to enhance visibility on trails and roadways, offering a reliable lighting solution across various driving environments.
_x000D_Construction and Appearance. Crafted with a powder-coated cast aluminum housing for increased durability and corrosion resistance, the light pod includes a hardcoated polycarbonate lens that protects the LEDs from impact and environmental elements. The sleek black finish is complemented by an integrated red backlight for an enhanced aesthetic appeal.
_x000D_Installation. Installation is straightforward with included stainless steel mounting hardware. The process typically does not require drilling, allowing for easy mounting on compatible surfaces.
_x000D_Warranty. The product comes with a limited lifetime warranty to ensure complete purchase protection.
_x000D_Application. Designed for universal fitment; however, some adaptation may be necessary depending on the vehicle or mounting location.
Baja Designs 270014
CA Residents:
WARNING: Cancer and Reproductive Harm - www.P65Warnings.ca.gov
Installation & What's in the Box
Installation Info
What's in the Box
- (1) LED Auxiliary Light Pod
- Mounting Bracket
- Hardware
5.0
Customer Reviews (1)
Questions & Answers
No questions about this product yet.
Ask the First Question
