Hushmat Ultra Hoodliner Heat Reflective Pads; 12-Inch x 23-Inch (Universal; Some Adaptation May Be Required)
Item FB36669
Our Price
$129.99 set of 6
Military, Medical & First Responders
$6.50 Available in XT Cash Rewards.
Confirm Eligibility
Confirm Eligibility
Choose options to add to cart.
Saved - View your saved items
We're sorry. We couldn't save this product at this time.
or use
Shop Owners Save More!
Sign up for our dealer program
Product Information
Features, Description, Q&A, Specs & Installation
Features
- Robust formulation designed for rugged and high-temperature engine side environments
- Rated from -30°F to 550°F for superior heat resistance
- Proprietary self-adhesive butyl rubber compound significantly reduces road noise and vibrations for a quieter ride
- Durable, heavy-duty construction designed for the rigor of underhood application
- Flexible and easy to mold to complex surfaces, offers easy installation without special tools or harmful chemical surface preparation
- Lightweight design offers minimal impact on overall vehicle weight
- Insulates custom painted hoods from excessive engine heat
- Cold flexibility: can be bent around a 25 mm mandrel at -30°C with no cracking or loss of adhesion
- Color: polymer black backing with 4 mil silver aluminum laminate
- Flexible and paintable aluminum laminate can be cut and shaped to fit various hood configurations and sizes
- Flammability: tested per FMVSS 302 and is self-extinguishing
- Hardness: 6.5 - 9.0 mm as per ASTM D-5
- Peel strength tested in 90-degree peel at crosshead speed of 300 mm per minute on a 25 mm-wide specimen
- R-Value of 9 for excellent thermal insulation
- Not considered a hazardous material; gloves recommended for handling
- Shelf life of at least 6 months when stored at 40°C or less
- Specific gravity approximately 1.47
- Can withstand 1-hour bake at 290°C with no deformation
- Thickness of 2.0 mm
- Country of origin: US
- Emissions compliance exempt
- Available to order
- Package dimensions: 26 x 14 x 3 inches
- Package weight: 5 pounds
- Universal fit; some adaptation may be required
Description
High-Temperature Insulation. The Hushmat Ultra Hoodliner Heat Reflective Pads (12-Inch x 23-Inch) provide superior thermal insulation for automotive hoods, especially under high engine heat conditions. Designed for use on the engine side of vehicle hoods, these pads help reduce heat transfer, protecting custom paint jobs and improving vehicle comfort.
Construction and Appearance. Made from a proprietary self-adhesive butyl rubber compound laminated with flexible, paintable aluminum foil, these pads feature a black polymer front with a slim aluminum backing. This durable 2.0 mm-thick material is designed to be flexible and mold easily to complex surfaces without the need for special tools or chemical surface preparation.
Installation. Installation is user-friendly and requires no drilling or special tools. The pads can be easily cut and shaped, and their self-adhesive backing enables quick application on various hood configurations.
Application. This product fits universally but may require some adaptation depending on the vehicle. It is suitable for use on a wide range of vehicles for underhood insulation and noise reduction purposes.
Hushmat 50100
CA Residents:
WARNING: Cancer and Reproductive Harm - www.P65Warnings.ca.gov
Installation & What's in the Box
Installation Info
What's in the Box
- (6) Heat Reflective Pads
