Installation Time
(approx) 1 Hour
Difficulty Level:
Light to Moderate mechanical skill required.
FREE 1 to 3-Day Delivery on Orders $149+ Details
Bilstein B8 8112 ZoneControl CR DSA+ Series Front Coil-Over Shock for 2.25 to 3.25-Inch Lift; Passenger Side (07-21 Tundra)Find parts that fit my vehicle
Item TU51031
Our Price
$1,293.00 each
Military, Medical & First Responders
$64.65 Available in XT Cash Rewards.
Confirm Eligibility
Confirm Eligibility
Item Options
Saved - View your saved items
We're sorry. We couldn't save this product at this time.
or use
Shop Owners Save More!
Sign up for our dealer program
Product Information
Features, Description, Reviews, Q&A, Specs & Installation
Features
- ZoneControl® CR Position Sensitive Damping with 3 Compression Zones and 2 Rebound Zones
- Dual Speed Adjustable Compression with Adjustable JCO Eliminates Need for External Hydraulic Bump Stop
- Secondary Rebound Stop Dissipates Spring Energy and Stabilizes Suspension After Large Compression Events
- Triple Piston Design Provides Comfort During Everyday Driving and Maximum Control Under Large Suspension Inputs
- Click Adjuster Knobs Allow Precise Dual Speed Adjustment of Low and High-Speed Compression Plus Adjustable JCO
- Adjustable Threaded Spring Seat for Fine-Tuned Ride Height; Adjustable Range 0-3.3 Inches Depending on Model
- 60mm Remote Reservoir Increases Oil Capacity and Cooling; Aluminum Finned Reservoir Available for Select Applications
- Vehicle Specific Design and Tuning Optimizes Wheel Travel and Clearance with Aerospace Quality Components
- High Quality Chrome 5/8 Inch Heim Joint Mounting with Rubber Sealed Misalignment Spacers for Durable Load Bearing
- Coilover Supplied as Complete Module with Spring Pre-Loaded to Factory Recommended Ride Height
- Owner Rebuildable and Revalvable
- Made in the USA
- Limited 2-Year Warranty
- Fits 07-21 Tundra
Description
Advanced Suspension Technology. The Bilstein B8 8112 ZoneControl CR DSA+ Series Front Coil-Over Shock for 2.25 to 3.25-Inch Lift; Passenger Side delivers industry-leading position sensitive damping with three compression zones and two rebound zones. Designed for drivers seeking superior comfort during routine driving and enhanced control over large suspension inputs, it offers precise tuning of compression speeds and a customizable hydraulic bump stop for individualized performance. This shock absorber ensures stability and performance across a variety of terrains by effectively managing both gradual and sharp suspension movements.
Construction and Appearance. Built with aerospace-quality components, this coil-over features a durable 60mm remote reservoir constructed with nitrogen-infused monotube technology and a floating dividing piston to separate gas and oil. The suspension includes high-quality chrome 5/8” heim joints with sealed misalignment spacers for robust, long-lasting mounting. The coil spring is pre-loaded and adjustable for ride height within a 0 to 3.3-inch range, allowing fine control over vehicle stance and suspension travel. The finish is engineered for durability and corrosion resistance, suitable for demanding off-road environments.
Installation. Installation is straightforward as the coilover is supplied as a complete, pre-assembled module with the spring pre-loaded to the recommended ride height. No drilling is required for fitment, making it a simple upgrade for those with moderate mechanical skills.
Warranty. This product includes a limited 2-year warranty providing assurance of quality and durability.
Application. Designed specifically for the 07-21 Tundra, this coil-over fits perfectly without modifications to provide optimized suspension performance and ride quality for this vehicle model.
Bilstein 41-326091
CA Residents:
WARNING: Cancer and Reproductive Harm - www.P65Warnings.ca.gov
Installation & What's in the Box
Installation Info
What's in the Box
- (1) Front Coil-Over Shock
