Baja Designs LP9 Sport LED Auxiliary Light Pod; Spot Beam; Clear (Universal; Some Adaptation May Be Required)
Item JG28486
Our Price
$510.35 each
Military, Medical & First Responders
$25.52 Available in XT Cash Rewards.
Confirm Eligibility
Confirm Eligibility
Choose options to add to cart.
Saved - View your saved items
We're sorry. We couldn't save this product at this time.
or use
Shop Owners Save More!
Sign up for our dealer program
Product Information
Features, Description, Q&A, Specs & Installation
Features & Specs
- _x000D_
- Lens Material Hardcoated Polycarbonate _x000D_
- Light Quantity 1 _x000D_
- Lighting Modes Beam _x000D_
- Lighting Quantity 9 _x000D_
- Lighting Technology LED _x000D_
- Lighting Type Forward Projecting _x000D_
- Mounting Hardware Included Yes _x000D_
- Mounting Hardware Material Stainless Steel _x000D_
- Overvoltage Protection Built-In _x000D_
- Secondary Amperage Rating 1.520 Amp _x000D_
- Secondary Brightness 2302 Lumens _x000D_
- Secondary Light Quantity 6 LEDs _x000D_
- Secondary Lighting Technology LED _x000D_
- Secondary Lighting Type Integrated Peripheral Technology IPT _x000D_
- Secondary Wattage 21 Watts _x000D_
- Terminal Connector DT06-4S Deutsch _x000D_
- Terminal Type Mating Connector _x000D_
- Wattage 88.320 Watts _x000D_
- Amperage Rating 6.400 Amp _x000D_
- Average Rated Life 49930 Hours _x000D_
- Beam Pattern Spot _x000D_
- Bezel Material Powder Coat Cast Aluminum _x000D_
- Brightness 9421 Lumens _x000D_
- Housing Color Black _x000D_
- Housing Material Powder Coat Cast Aluminum _x000D_
- Patent Number 5,504,603 _x000D_
- Standards Compliance Exceeds MIL-STD810G Mil-Spec Testing _x000D_
- Impact Resistance IK10 Compliant Mechanical Impact Testing _x000D_
- Water Resistance IP69K Waterproof Up To 9ft And Pressure Washable _x000D_
- Depth 3.250 Inches _x000D_
- Height 8 Inches _x000D_
- Length 8 Inches _x000D_
- Weight 6.50 Pounds _x000D_
- Fits Universal; Some Adaptation May Be Required _x000D_
| Brand | Baja Designs |
| Bulb Type | LED |
| Light Shape | Round |
| Light Size | 8 Inch and Up |
Description
Advanced Auxiliary Lighting. The Baja Designs LP9 Sport LED Auxiliary Light Pod; Spot Beam; Clear is engineered for off-road and auxiliary vehicle lighting needs, delivering high-intensity illumination with a spot beam pattern. It is designed to enhance visibility in challenging conditions by projecting focused, powerful light, improving driver awareness and safety.
_x000D__x000D_Construction and Appearance. This light pod features a durable powder coat cast aluminum housing and bezel, finished in black for corrosion resistance and aesthetics. The lens is constructed from hardcoated polycarbonate, providing impact resistance and clarity, ensuring longevity and performance in rugged environments.
_x000D__x000D_Installation. Installation of this unit is straightforward with included stainless steel mounting hardware, requiring minimal effort and no special tools for typical mounts. The design does not require drilling, facilitating quick set-up on a wide range of vehicles and mounting locations.
_x000D__x000D_Warranty. This product is backed by a limited lifetime warranty, offering complete purchase protection against defects and ensuring customer confidence.
_x000D__x000D_Application. Fits universally with some adaptation may be required to accommodate specific vehicle mounting points or configurations.
Baja Designs 350001
CA Residents:
WARNING: Cancer and Reproductive Harm - www.P65Warnings.ca.gov
Installation & What's in the Box
Installation Info
What's in the Box
- (1) LED Light
