2020-2026
Installation Time
(approx) 45 Minutes
Difficulty Level:
Simple installation for anyone.
FREE 1 to 3-Day Delivery on Orders $149+ Details
Find Light Bars & Off-Road Lighting for your Gladiator
Baja Designs LP9 Sport LED Auxiliary Light Pod; Driving/Combo Beam; Clear (Universal; Some Adaptation May Be Required)
Item JG28484
Our Price
$463.95 each
Military, Medical & First Responders
$23.20 Available in XT Cash Rewards.
Confirm Eligibility
Confirm Eligibility
Choose options to add to cart.
Saved - View your saved items
We're sorry. We couldn't save this product at this time.
or use
Shop Owners Save More!
Sign up for our dealer program
Product Information
Features, Description, Q&A, Specs & Installation
Features & Specs
- _x000D_
- Lens Color Clear _x000D_
- Lens Material Hardcoated Polycarbonate _x000D_
- Light Quantity 1 _x000D_
- Lighting Modes High Beam/Low Beam/Day-Time Running Backlighting _x000D_
- Lighting Quantity 9 _x000D_
- Lighting Technology LED _x000D_
- Lighting Type Forward Projecting _x000D_
- Mounting Hardware Included Yes _x000D_
- Mounting Hardware Material Stainless Steel _x000D_
- Overvoltage Protection Built-In _x000D_
- Secondary Amperage Rating 1.520 A _x000D_
- Secondary Brightness 2302 Lumens _x000D_
- Secondary Light Quantity 6 LEDs _x000D_
- Secondary Lighting Technology LED _x000D_
- Secondary Lighting Type Integrated Peripheral Technology (IPT) _x000D_
- Secondary Wattage 21 W _x000D_
- Terminal Connector DT06-4S Deutsch _x000D_
- Terminal Type Mating Connector _x000D_
- Universal Or Specific Universal _x000D_
- Wattage 124.200 W _x000D_
- Wiring Harness Included No _x000D_
- Amperage Rating 9 A _x000D_
- Average Rated Life 49,930 Hours _x000D_
- Backlight Amperage Rating 0.200 A _x000D_
- Backlight Wattage 2.800 W _x000D_
- Beam Pattern Spot _x000D_
- Bezel Material Powder Coat Cast Aluminum _x000D_
- Brightness 12,547 Lumens _x000D_
- Description Spot; Clear _x000D_
- Housing Color Black _x000D_
- Housing Material Powder Coat Cast Aluminum _x000D_
- Patent Number 5,504,603 _x000D_
- Standards And Compliance Durability Exceeds MIL-STD810G (Mil-Spec Testing) _x000D_
- Standards And Compliance Impact Resistance IK10 Compliant (Mechanical Impact Testing) _x000D_
- Standards And Compliance Water Resistance IP69K (Waterproof up to 9ft & Pressure Washable) _x000D_
- Depth 3.250 Inches _x000D_
- Height 8 Inches _x000D_
- Length 8 Inches _x000D_
- Weight 6.500 Pounds _x000D_
- Fits Universal; Some Adaptation May Be Required _x000D_
| Brand | Baja Designs |
| Bulb Type | LED |
| Light Shape | Round |
| Light Size | 8 Inch and Up |
Description
High-Performance LED Lighting. The Baja Designs LP9 Sport LED Auxiliary Light Pod; Driving/Combo Beam; Clear is engineered to deliver superior forward illumination with exceptional brightness and a wide lighting spread. It is designed for off-road enthusiasts and professionals seeking enhanced visibility during both near-field and long-distance driving conditions.
_x000D_Robust Construction and Appearance. This light pod features a housing made from powder-coated cast aluminum with a black finish for durability and corrosion resistance. It includes a hardcoated polycarbonate lens for impact protection and employs stainless steel mounting hardware for secure installation and longevity.
_x000D_Installation. Installation is moderately straightforward with included stainless steel mounting hardware. Drilling may be required depending on the vehicle's mounting location and setup.
_x000D_Warranty. The product is backed by a limited lifetime warranty, providing complete purchase protection.
_x000D_Application. Fits universal applications; some adaptation may be required.
Baja Designs 350003
CA Residents:
WARNING: Cancer and Reproductive Harm - www.P65Warnings.ca.gov
Installation & What's in the Box
Installation Info
What's in the Box
- (1) LP9 Sport LED Auxiliary Light Pod
4.7
Reviews of Baja Designs Lights Products (162)
Questions & Answers
No questions about this product yet.
Ask the First Question
