How to Install DV8 Off-Road Front Aluminum Inner Fender Flares - Raw (07-18 Wrangler JK) on your Jeep Wrangler

Installation Time

1 hours

Tools Required
  • Box Cutter/Knife
  • 10mm Socket
  • Socket Wrench
  • Allen Wrench
Extreme Terrain
Shop Parts in this Guide

1. Carefully open the package using a box cutter or knife (Figure A) and ensure the hardware is included and undamaged.


Figure A

2. Remove the factory fender liner using a 10mm socket wrench (Figure B). Note: Keep hardware removed.


Figure B

3. Mount the solid, inner half of the inner fender first, reusing the 10mm factory bolt removed in Step 2 (Figure C).


Figure C

4. Place the arm (supplied -side specific) behind the bulkhead with the notched side facing down and toward the engine (Figure D).


Figure D

5. Secure the arm to the liner using the long screw provided and an Allen wrench through the liner hole (Figure E).


Figure E

6. Move the front half of the inner fender into place, beginning with the bottom side first (Figure F).


Figure F

7. Using the factory bolts, mount the front inner fender into place (Figure G).


Figure G

8. Align the two halves by pressing back until the holes line up and inserting two shorter screws (Figure H).


Figure H

9. Tighten the bolts (Figure I).


Figure I

10. Repeat Steps 2-9 on the other side.


Before

After

Installation Instructions Written by Extreme Terrain Customer J. Sandlin 02/28/2018
