Installation Time
(approx) 45 Minutes
Difficulty Level:
Simple installation for anyone.
FREE 1 to 3-Day Delivery on Orders $149+ Details
Find Light Bars & Off-Road Lighting for your Frontier
Baja Designs LP9 Sport LED Auxiliary Light Pod; Driving/Combo Beam; Clear (Universal; Some Adaptation May Be Required)
Item NF8425
Our Price
$463.95 each
Military, Medical & First Responders
$23.20 Available in XT Cash Rewards.
Confirm Eligibility
Confirm Eligibility
Choose options to add to cart.
Saved - View your saved items
We're sorry. We couldn't save this product at this time.
or use
Shop Owners Save More!
Sign up for our dealer program
Product Information
Features, Description, Q&A, Specs & Installation
Features & Specs
- _x000D_
- Lens Color Clear _x000D_
- Lens Material Hardcoated Polycarbonate _x000D_
- Light Quantity 1 _x000D_
- Lighting Modes High Beam/Low Beam/Day-Time Running Backlighting _x000D_
- Lighting Quantity 9 _x000D_
- Lighting Technology LED _x000D_
- Lighting Type Forward Projecting _x000D_
- Mounting Hardware Included Yes _x000D_
- Mounting Hardware Material Stainless Steel _x000D_
- Overvoltage Protection Built-In _x000D_
- Product Type LP9 Pro LED Light Pod _x000D_
- Secondary Amperage Rating 1.520 A _x000D_
- Secondary Brightness 2302 Lumens _x000D_
- Secondary Light Quantity 6 LEDs _x000D_
- Secondary Lighting Technology LED _x000D_
- Secondary Lighting Type Integrated Peripheral Technology IPT _x000D_
- Secondary Wattage 21 W _x000D_
- Terminal Connector DT06-4S Deutsch _x000D_
- Terminal Type Mating Connector _x000D_
- Universal Or Specific Universal _x000D_
- Wattage 124.2 W _x000D_
- Wiring Harness Included No _x000D_
- Amperage Rating 9 A _x000D_
- Average Rated Life 49,930 Hours _x000D_
- Backlight Amperage Rating 0.200 A _x000D_
- Backlight Wattage 2.8 W _x000D_
- Beam Pattern Spot _x000D_
- Bezel Material Powder Coat Cast Aluminum _x000D_
- Brightness 12,547 Lumens _x000D_
- Description Spot; Clear _x000D_
- Housing Color Black _x000D_
- Housing Material Powder Coat Cast Aluminum _x000D_
- Standards Compliance Exceeds MIL-STD810G Mil-Spec Testing _x000D_
- Impact Resistance IK10 Compliant Mechanical Impact Testing _x000D_
- Water Resistance IP69K Waterproof Up To 9ft & Pressure Washable _x000D_
- Dimensions Depth 3.25in _x000D_
- Dimensions Height 8in _x000D_
- Dimensions Length 8in _x000D_
- Weight 6.5 lbs _x000D_
- Fits Universal; Some Adaptation May Be Required _x000D_
| Brand | Baja Designs |
| Bulb Type | LED |
| Light Shape | Round |
| Light Size | 8 Inch and Up |
Description
High-Performance Lighting. The Baja Designs LP9 Sport LED Auxiliary Light Pod; Driving/Combo Beam; Clear is engineered to deliver outstanding illumination for off-road and auxiliary applications. Featuring a combination of spot and driving beam patterns, it provides exceptional trail coverage and distance visibility, enhancing safety and driving capability in demanding conditions.
_x000D__x000D_Construction and Appearance. This light pod is crafted from powder-coated cast aluminum for durability and heat dissipation, with a black finish for a sleek, rugged look. The lens is made from hardcoated polycarbonate to resist damage and maintain clarity, and the mating connector uses a robust DT06-4S Deutsch terminal, ensuring reliable electrical connections.
_x000D__x000D_Installation. Installation requires moderate skills and basic tools, with mounting hardware included for convenience. The unit typically installs without drilling, fitting standard auxiliary mounting points or brackets.
_x000D__x000D_Warranty. This product is covered by a limited lifetime warranty, protecting against defects and ensuring long-term reliability. Application. Fits universal applications; some adaptation may be required to fit specific mounting setups.
Baja Designs 350003
CA Residents:
WARNING: Cancer and Reproductive Harm - www.P65Warnings.ca.gov
Installation & What's in the Box
Installation Info
What's in the Box
- (1) LP9 Sport LED Auxiliary Light Pod
