Rancho RS9000XL Rear Shock for 4-Inch Rancho Suspension Lift Kit (04-15 Titan)

Find parts that fit my vehicle Item NT9380
Shop Owners Save More! Sign up for our dealer program

    Product Information

    Features, Description, Reviews, Q&A, Specs & Installation

    Features & Specs

    • Nine Levels Of Performance With Manually Adjustable Knob For Custom Damping Control
    • Designed For Stock Or Lifted Trucks, SUVs, And Jeeps That Tow, Haul, Or Go Off Road
    • Industry-First Nine-Position Manually Adjustable Shock Series
    • Nitrogen Gas Pressurized To 120 PSI To Reduce Damping Fade And Foaming
    • 18mm Nitro-Carburized Piston Rod For Resistance To Scuffs And Corrosion
    • Double-Welded Loops At Stress Areas For Enhanced Durability
    • 1.25-Inch Sintered Iron Piston For Structural Integrity
    • Up To 2.75-Inch Tri-Tube Body Filled With All-Weather Fluid For Cooler Operation
    • Operates In Temperatures Ranging From -40 To 248°F
    • Polyurethane Rebound Bumper And Bushings With Graphite-Filled Fluon Band Piston For Smooth Ride
    • Low-Friction, Self-Lubricating Seal For Quicker Rebound And Smoother Compression
    • Premium Liquid Metallic Finish And Polyvinyl Protective Boot For Extended Life
    • Manual Damping Adjustment
    • Loop Bushing And Sleeve Mounts
    • Extended Length Of 27.19 Inches
    • Shock Stroke Of 10.23 Inches
    • Boot Included
    • Gas Charged
    • Body Diameter Of 2.38 Inches
    • Rod Diameter Of 18 Millimeters
    • Tri Tube Internal Construction
    • Progressive Valving Type
    • Coated Silver Finish
    • Fits 04-15 Titan, Rear Position With 4-Inch Rear Raised Height Using Rancho Suspension System, To Be Replaced By RS994304 Upon Depletion

    Description

    Adjustable Performance Shock. The Rancho Rear RS9000XL Shock provides premium ride control with nine easy-to-adjust levels, allowing custom damping for various driving conditions including on-road, off-road, towing, and hauling. This shock absorber enhances vehicle control, ensuring a balanced and smooth ride experience across demanding terrains.

    Construction and Appearance. Built for durability, this shock features an 18mm nitro-carburized piston rod that resists corrosion and scuffs, along with a 1.25-inch sintered iron piston for strength. It utilizes a tri-tube body filled with all-weather fluid to maintain cooler operation and performs reliably under extreme temperatures. The silver metallic finish and polyvinyl protective boot promote long-lasting protection against elements.

    Installation. Installation of the RS9000XL shock is straightforward for experienced individuals, requiring no drilling or fabrication. It is designed to fit directly with existing mounts for a convenient upgrade.

    Warranty. This shock absorber is backed by a limited lifetime warranty, guaranteeing durability and performance.

    Application. Specifically engineered for rear installation on 2004 to 2015 Titan models with a 4-inch rear lift using Rancho Suspension Systems. It should be used until depletion, at which point the RS994304 is recommended as a replacement.

    Rancho RS994304

    CA Residents: WARNING: Cancer and Reproductive Harm - www.P65Warnings.ca.gov

    Install Details & What's in the Box

    Installation Info

    Installation Time

    (approx) a Day

    Difficulty Level:

    Mechanical expertise or professional installation required.

    Installation Guides

      No guide available for this part yet.

    What's in the Box

    • (1) Rear Shock for 4-Inch Lift
    4.8

    Customer Reviews (183)

    Questions & Answers

    No questions about this product yet. Ask the First Question
