Baja Designs Squadron-R SAE LED Auxiliary Light Pods; Clear (Universal; Some Adaptation May Be Required)
Item NT14547
Our Price
$349.95 pair
Military, Medical & First Responders
$17.50 Available in XT Cash Rewards.
Confirm Eligibility
Confirm Eligibility
Choose options to add to cart.
Saved - View your saved items
We're sorry. We couldn't save this product at this time.
or use
Shop Owners Save More!
Sign up for our dealer program
Product Information
Features, Description, Q&A, Specs & Installation
Features & Specs
- _x000D_
- Next Generation Squadron SAE Road-Legal Auxiliary Fog Light _x000D_
- All-New Aspheric Projector Optics _x000D_
- Advanced LED Technology _x000D_
- Performance Increase In Luminous Flux Of 56 Percent Over Previous Generation _x000D_
- Delivers 2,420 Lumens Per Light _x000D_
- Output Reaches Up To 15,800 Candela At 29 Watts _x000D_
- Illuminates Zone 1 With Controlled, Sharp Cutoff _x000D_
- Complies With SAE J583 Fog Lamp Requirements _x000D_
- Highly Controlled Light Pattern With Sharp Cutoff For Dust, Fog, Inclement Weather _x000D_
- Limited Lifetime Warranty And 30-Day Satisfaction Guarantee _x000D_
- Exceeds Mil-Std810G Durability Standards _x000D_
- IP69K Waterproof 9ft And Pressure Washable _x000D_
- IK10 Mechanical Impact Resistance _x000D_
- Housing Material Hard Anodized And Powder Coated Cast Aluminum _x000D_
- Lens Material Hardcoated Polycarbonate _x000D_
- Bezel Material Powder Coated Cast Aluminum _x000D_
- Light Type Cree LED With Forward Projecting Technology _x000D_
- Amperage Rating 2.1 Amps _x000D_
- Average Rated Life 49,930 Hours _x000D_
- Wattage 29 Watts _x000D_
- Includes Stainless Steel Mounting Hardware And Wiring Harness _x000D_
- Built-In Overvoltage Protection _x000D_
- Weight 0.75 Pounds Each _x000D_
- Dimensions 3.07 Inches Height, 3.07 Inches Length, 2.77 Inches Depth _x000D_
- Street Legal, Not DOT Approved _x000D_
- Fits Universal; Some Adaptation May Be Required _x000D_
| Brand | Baja Designs |
| Bulb Type | LED |
| Light Shape | Round |
| Light Size | 3 to 3.75 Inch |
Description
ROAD-LEGAL FOG LIGHTS. The Baja Designs Squadron-R SAE LED Auxiliary Light Pods; Clear offer highly effective, controlled fog lighting designed to improve visibility in dust, fog, and harsh weather conditions. These lights provide a sharp cutoff beam pattern that maximizes useful illumination while preventing glare for oncoming drivers, enhancing safety on both road and trail.
_x000D__x000D_PREMIUM CONSTRUCTION AND APPEARANCE. Crafted from hard anodized and powder coated cast aluminum, the housing provides superior durability and corrosion resistance. The lens is made from hardcoated polycarbonate for impact resistance and longevity, while the bezel features powder coated cast aluminum for added strength and a sleek black finish.
_x000D__x000D_INSTALLATION. Installation is straightforward with included stainless steel mounting hardware and wiring harness. No complex modifications or drilling are typically required, making it accessible for both professional installers and enthusiasts.
_x000D__x000D_WARRANTY. Backed by a limited lifetime warranty that covers manufacturing defects and performance failures, ensuring long-term reliability and peace of mind.
_x000D__x000D_APPLICATION. Fits universally with some adaptation required depending on vehicle setup or mounting preferences. Designed to comply with SAE J583 fog lamp requirements for street legality but not DOT approved for all jurisdictions.
Baja Designs 247802
CA Residents:
WARNING: Cancer and Reproductive Harm - www.P65Warnings.ca.gov
Installation & What's in the Box
Installation Info
What's in the Box
- (2) LED Auxiliary Light Pods
- Installation Hardware
