Baja Designs LP9 Sport LED Auxiliary Light Pod; Driving/Combo Beam; Clear (Universal; Some Adaptation May Be Required)
Item NT14510
Our Price
$463.95 each
Military, Medical & First Responders
$23.20 Available in XT Cash Rewards.
Confirm Eligibility
Confirm Eligibility
Choose options to add to cart.
Saved - View your saved items
We're sorry. We couldn't save this product at this time.
or use
Shop Owners Save More!
Sign up for our dealer program
Product Information
Features, Description, Q&A, Specs & Installation
Features & Specs
- _x000D_
- Lens Color Clear _x000D_
- Lens Material Hardcoated Polycarbonate _x000D_
- Light Quantity 1 _x000D_
- Lighting Modes High Beam/Low Beam/Day-Time Running Backlighting _x000D_
- Lighting Quantity 9 _x000D_
- Lighting Technology LED _x000D_
- Lighting Type Forward Projecting _x000D_
- Mounting Hardware Included Yes _x000D_
- Mounting Hardware Material Stainless Steel _x000D_
- Overvoltage Protection Built-In _x000D_
- Product Type LP9 Pro LED Light Pod _x000D_
- Secondary Amperage Rating 1.520 A _x000D_
- Secondary Brightness 2,302 Lumens _x000D_
- Secondary Light Quantity 6 LEDs _x000D_
- Secondary Lighting Technology LED _x000D_
- Secondary Lighting Type Integrated Peripheral Technology IPT _x000D_
- Secondary Wattage 21 W _x000D_
- Terminal Connector DT06-4S Deutsch _x000D_
- Terminal Type Mating Connector _x000D_
- Universal Or Specific Universal _x000D_
- Wattage 124.2 W _x000D_
- Wiring Harness Included No _x000D_
- Amperage Rating 9 A _x000D_
- Average Rated Life 49,930 Hours _x000D_
- Backlight Amperage Rating 0.200 A _x000D_
- Backlight Wattage 2.8 W _x000D_
- Beam Pattern Spot _x000D_
- Bezel Material Powder Coat Cast Aluminum _x000D_
- Brightness 12,547 Lumens _x000D_
- Description Spot Clear _x000D_
- Housing Color Black _x000D_
- Housing Material Powder Coat Cast Aluminum _x000D_
- Exceeds MIL-STD810G Durability Standard _x000D_
- IK10 Compliant Impact Resistance _x000D_
- IP69K Waterproof And Pressure Washable _x000D_
- Dimensions 8" Height x 8" Length x 3.25" Depth _x000D_
- Weight 6.5 Pounds _x000D_
- Fits Universal; Some Adaptation May Be Required _x000D_
| Brand | Baja Designs |
| Bulb Type | LED |
| Light Shape | Round |
| Light Size | 8 Inch and Up |
Description
High-Performance Lighting. The Baja Designs LP9 Sport LED Auxiliary Light Pod delivers exceptional illumination with forward projecting LEDs and Integrated Peripheral Technology (IPT), providing both a focused long-distance beam and a wide 200-degree spread for enhanced trail visibility and safety in off-road conditions.
_x000D__x000D_Construction and Appearance. Crafted with a durable powder-coated cast aluminum housing and a hardcoated polycarbonate lens, this light pod offers robust protection with a sleek black finish. Included stainless steel mounting hardware ensures secure installation and lasting resilience in demanding environments.
_x000D__x000D_Installation. Installation is straightforward with the included stainless steel mounting hardware and typically requires no drilling, depending on your mounting location. Basic mechanical skills and common tools are sufficient for a secure fit.
_x000D__x000D_Warranty. This product includes a limited lifetime warranty, offering long-term protection against defects.
_x000D__x000D_Application. Designed for universal fitment, some adaptation may be necessary depending on your vehicle and mounting setup.
Baja Designs 350003
CA Residents:
WARNING: Cancer and Reproductive Harm - www.P65Warnings.ca.gov
Installation & What's in the Box
Installation Info
What's in the Box
- (1) LP9 Sport LED Auxiliary Light Pod
